Failed small end bearing

Post by Lee24V » Sun Jun 17, 2018 9:18 pm

Spoken to 3 mechanics today and the diagnosis is a small end bearing thats gone.

Anybody have any advice for changing these who have done it before ?
javascript:void(0);


Lee24V
UKPOC Full Member
Posts: 761
Joined: Tue Oct 17, 2006 10:47 am
Location: Sheffield

Re: Failed small end bearing

Post by Lee24V » Fri Jun 29, 2018 5:02 pm

Never mind, turns out the big end bearing has spun for some reason and the engine is officially knackered ๐Ÿ™.
javascript:void(0);


User avatar
Placid Probe
SC Regional Rep
Posts: 1366
Joined: Tue Sep 02, 2008 4:27 pm
Drives: 1 x 24v / 1 x 16v
Location: Surrey

Re: Failed small end bearing

Post by Placid Probe » Fri Jun 29, 2018 6:09 pm

Sorry to hear this.

Are you going to fix it?

How many miles had the engine done?

2ND PLACE STD 16V - 2014
2ND PLACE STD 16V - 2015
2ND PLACE STD 16V - 2016

Lee24V
UKPOC Full Member
Posts: 761
Joined: Tue Oct 17, 2006 10:47 am
Location: Sheffield

Re: Failed small end bearing

Post by Lee24V » Fri Jun 29, 2018 7:01 pm

Well i rebuilt the engine meticulously last year, didnt replace the shells but somethings gone wrong somewhere, its done 114k and 4k since rebuild. Just deciding how to go ahead with it tbh
javascript:void(0);


User avatar
EL PLATES
UKPOC Full Member
Posts: 4489
Joined: Tue Nov 02, 2010 12:33 am
Drives: 95 2.5 V6 BLUE
Location: East Anglia

Re: Failed small end bearing

Post by EL PLATES » Fri Jun 29, 2018 7:04 pm

oh dear, sorry to hear....

dont even know what parts you are talking about.

all the best

hope you are able to get things sorted...

:wave: :wave: :wave: :wave:

Lee24V
UKPOC Full Member
Posts: 761
Joined: Tue Oct 17, 2006 10:47 am
Location: Sheffield

Re: Failed small end bearing

Post by Lee24V » Sat Jun 30, 2018 8:43 am

Thanks, i am going to check what damage has been done today and see what i need to do to sort it
javascript:void(0);


Kit
UKPOC Tech Guru "Brakes"
Posts: 3803
Joined: Thu Jul 20, 2006 1:17 pm
Drives: 16v Teal
Location: BASILDON

Re: Failed small end bearing

Post by Kit » Tue Jul 03, 2018 8:06 pm

EL PLATES wrote: โ†‘
Fri Jun 29, 2018 7:04 pm
oh dear, sorry to hear....

dont even know what parts you are talking about.

all the best

hope you are able to get things sorted...

:wave: :wave: :wave: :wave:
There the bits either end of the conrods, any wiser now, :rolleyes: :rolleyes: ](*,)

Kit
Duncan & Jan
16vChameleon 1997 needs an MOT-on going Project , Mine 16v Rio Red 1996 (Probefest Shed of the Show 09 !) needs a bit of TLC to the engine , Driving at Present Black GEN 1 & 4 other 16v project car's!

UKPOC member 0072
PaulS Memorial Award Joint Holder 2012

User avatar
EL PLATES
UKPOC Full Member
Posts: 4489
Joined: Tue Nov 02, 2010 12:33 am
Drives: 95 2.5 V6 BLUE
Location: East Anglia

Re: Failed small end bearing

Post by EL PLATES » Wed Jul 04, 2018 12:44 am

cheeky bugger ......
:nana: :nana:

Lee24V
UKPOC Full Member
Posts: 761
Joined: Tue Oct 17, 2006 10:47 am
Location: Sheffield

Re: Failed small end bearing

Post by Lee24V » Wed Jul 04, 2018 12:45 pm

Well i have had my micrometer on the crankshaft and it seems the damage was just to the shells, so going to try those and see how it goes ๐Ÿคž
javascript:void(0);


flex
UKPOC Full Member
Posts: 4714
Joined: Sun Sep 02, 2007 9:49 pm
Drives: sbm 24v
Location: kettering northants

Re: Failed small end bearing

Post by flex » Wed Jul 04, 2018 12:59 pm

Fingers crossed for you mate.

User avatar
Andy W
UKPOC Full Member
Posts: 17739
Joined: Mon Apr 25, 2005 9:59 pm
Drives: 94 probe 16v
Location: County Durham Drives: rio red 16v

Re: Failed small end bearing

Post by Andy W » Thu Jul 05, 2018 3:09 pm

Good luck Lee

jrh
UKPOC Full Member
Posts: 422
Joined: Wed May 13, 2009 9:37 pm
Drives: 94probe

Re: Failed small end bearing

Post by jrh » Thu Jul 05, 2018 5:21 pm

Make sure you haven't 'lost' any flakes of bearing material .
If you cannot account for every 'lost' piece it will be 'in the system ' having avoided the filter.
I needn't describe what will happen next.

Lee24V
UKPOC Full Member
Posts: 761
Joined: Tue Oct 17, 2006 10:47 am
Location: Sheffield

Re: Failed small end bearing

Post by Lee24V » Thu Jul 05, 2018 5:37 pm

Yeah i have got all the bits and i have cleaned the sump.

Just waiting on the shells now.
javascript:void(0);


jrh
UKPOC Full Member
Posts: 422
Joined: Wed May 13, 2009 9:37 pm
Drives: 94probe

Re: Failed small end bearing

Post by jrh » Thu Jul 05, 2018 7:32 pm

Next , try to figure out why that bearing failed.
Make sure you turn that engine over by hand , NOT the starter motor , and really 'feel' if there is any sign of tightness or obstruction when that
cylinder passes over TDC.
Good luck.

Lee24V
UKPOC Full Member
Posts: 761
Joined: Tue Oct 17, 2006 10:47 am
Location: Sheffield

Re: Failed small end bearing

Post by Lee24V » Thu Jul 05, 2018 9:48 pm

I have had a thorough check and nothing found yet. Me and few other mechanics think its oil starvation to that bearing. I have checked the oil channels and theyre clear. Something has made the bearings grab, break the tabs then spin.
javascript:void(0);


jrh
UKPOC Full Member
Posts: 422
Joined: Wed May 13, 2009 9:37 pm
Drives: 94probe

Re: Failed small end bearing

Post by jrh » Fri Jul 06, 2018 12:27 pm

From the Ford book, standard con rod bearing clearance is 0.023mm to 0.043mm.
Maximum clearance 0.08mm.
Check with plastigauge or similar.
Cross your fingers.

humph
UKPOC Full Member
Posts: 372
Joined: Sun Jun 01, 2008 5:40 pm
Drives: Probe 24V 94 model
Location: Luton.

Re: Failed small end bearing

Post by humph » Tue Jul 10, 2018 4:19 pm

I always use assembly lube on all bearing when reassembling an engine.
Paul.

Electric Blue 24V
Mazda RX8 PZ

Lee24V
UKPOC Full Member
Posts: 761
Joined: Tue Oct 17, 2006 10:47 am
Location: Sheffield

Re: Failed small end bearing

Post by Lee24V » Thu Jul 12, 2018 9:34 am

Well, as i suspected, the spun bearing has created wear on the crankshaft, so engine out time Again ๐Ÿ˜” and swap the complete block for the spare i have.
